Evolution in Raised Access Floor Systems
•  High density chipboard core E1 class, 650 kg/m3, bonded with a moisture
   curing adhesive into a patented double folded lock of fully encapsulated
   0.5mm hot deep galvanized steel.
•  Panel dimensions: 600*600*29 mm / 9,6 kg.
• The dimensional tolerances ratedas per UNI EN 12825 at the highest Class 1.

2009 Joint Pavimenti Bulgaria, Sofia 1408, 105A "Nishava" street, e-mail: info@dvoenpod.net, phone: +359.2.48.30.478,  mob: +359.899.99.66.72
•  Load baring Performances as per UNI EN 12825 stringerless at FFH 400mm

•  Point load at weakest point                                         > 4.12 kN
•  Ultimate load  with Safety Factor 3                               > 9.90 kN
•  Working load fixed deflection < 2.5 mm                        > 4.00 kN
•  RATED CLASS AS PER UNI EN 12825                           4/3,0/A/1
•  Fire Performance

•  Fire reaction EN 13501-1:                                       Class 1, Bfl-S1
•  Fire resistance EN 13501-2:                                R.E.I. 30, R.E.90
•  Fire rate as per  PSAMOB:             Index i1, Class 1,Rating class 0
•  Noise Attenuation EN 20140-9 & EN 20140 - 6:

•  Air bone noise as per ISO 717 - 1 Dn1f1w:                        > 46 dB
•  Impact noise as per ISO 717 - 2 Ln1w:                             < 69 dB
C4TTM - Medium Grade
•  Proposed for office and commercial use.
•  Used as working platform during construction.
•  Water and reagents poof.

•
25 YEARS WARRANTY
Download C4TTM technical info
